CBD66113D

CBD66113D
View 3D Model
To view 3D models, you will need to open the pdf with Adobe Reader.
Specification
Type Drum
Diameter 410
Height 232
Thickness 188
Hub 298
PCD 335
Holes 10
Vehicle Application
Vehicle Attributes Year Wheel
ALEXANDER DENNIS ALX300 [2007-] - MAN 18.240 chassis drum brakes with 180mm linings01/2007 - PresentFront
MAN City Bus [1993-96] - 18. (220, 230, 250, 310, 313, 350, 370, 400, 420) HOCL 01/1993 - 12/1996Front
MAN City Bus [1999-] - 24. (400, 440, 460) HOCLN with Drum brake01/1999 - PresentFront
MAN City Bus [2006-] - 18. (220, 240, 280, 310, 360, 400, 440) with Drum brake01/2006 - PresentFront
MAN F2000 Series [1994-2005] - 18-50T 01/1994 - 12/2005Front
MAN F90 Series [86-1997] - F90 Series 06/1986 - 12/1997Front
MAN FE Series [1994-2005] - 18-50T 01/1994 - 12/2005Front
MAN L2000 [1993-09] - 18T 4X2 01/1995 - 12/2006Front
MAN L2000 [1993-09] - 19T 4X2 01/1995 - 12/2006Front
MAN L2000 [1993-09] - 26T 6X4 01/1999 - 12/2007Front
MAN LE Series [1993-09] - 18T 4X2 01/1995 - 12/2006Front
MAN LE Series [1993-09] - 19T 4X2 01/1995 - 12/2006Front
MAN LE Series [1993-09] - 26T 6X4 01/1999 - 12/2007Front
MAN TGA Series [2000-2013] - 19T 4X2 01/2000 - 12/2013Front
MAN TGA Series [2000-2013] - 26T 6X4 01/2000 - 12/2013Front
MAN TGA Series [2000-2013] - 32T 8X4 01/2000 - 12/2013Front
MAN TGA Series [2000-2013] - 33T 6X4 01/2000 - 12/2013Front
MAN TGA Series [2000-2013] - 35T 8X2-4 01/2000 - 12/2013Front
MAN TGA Series [2000-2013] - 35T 8X2-6 01/2000 - 12/2013Front
MAN TGA Series [2000-2013] - 35T 8X4 Drum brake Front & Rear01/2000 - 12/2013Front
MAN TGA Series [2000-2013] - 41T 8X2-4 01/2000 - 12/2013Front
MAN TGA Series [2000-2013] - 41T 8X2-6 01/2000 - 12/2013Front
MAN TGA Series [2000-2013] - 41T 8X4 01/2000 - 12/2013Front
MAN TGA Series [2000-2013] - 50T 8X4 01/2000 - 12/2013Front
MAN TGS Series [2006-2013] - 18T 4X2 01/2006 - 12/2013Front
MAN TGS Series [2006-2013] - 26T 6X4 01/2006 - 12/2013Front
MAN TGS Series [2006-2013] - 33T 6X4 01/2006 - 12/2013Front
MAN TGS Series [2006-2013] - 41T 8X4 01/2006 - 12/2013Front
MAN TGX Series [2006-2013] - 18T 4X2 01/2006 - 12/2013Front
MAN TGX Series [2006-2013] - 24T 6X4 01/2006 - 12/2013Front
MAN TGX Series [2006-2013] - 33T 6X4 Front & Rear, drum brake01/2006 - 12/2013Front
